列管冷凝器
發布時間:2018-06-22 點擊次數:3149 次
|
|
我廠生產的列管冷凝器,按材質分為碳鋼列管冷凝、不銹鋼列管式冷凝器和碳鋼與不銹鋼混合列管式冷凝三種,按形式分為固定管板式、浮頭式、U型管式換熱器, 按結構分為單管程、雙管程和多管程。傳熱面積0.5-500m
2,可根據用戶需要定制。
公稱直徑
|
管程數
|
管子數量
|
換熱面積 公稱值/計算值 |
管程通道截面積 管程通道流速為0.5m/sec時的流量m/hr |
公稱
壓力 |
管子長度 |
φ25×2.5 |
1500 |
2000 |
3000 |
4000 |
6000 |
φ25×2 |
159 |
1 |
14 |
1.5/1.62 |
22.17 |
33.27 |
|
|
0.0044/0.0049 |
7.92/8.82 |
0.25 |
219 |
1 |
26 |
3/3.00 |
4/4.02 |
6/6.06 |
8/8.1 |
|
0.0082/0.0090 |
14.76/16.20 |
0.6 |
|
2 |
26 |
3/3.00 |
4/4.02 |
6/6.06 |
8/8.81 |
|
0.0041/0.0045 |
7.38/8.01 |
1.0 |
273 |
1 |
44 |
5/5.08 |
7/5.18 |
10/10.26 |
14/13.72 |
21/20.63 |
0.0138/0.0152 |
24.84/27.36 |
1.6 |
|
2 |
40 |
5/4.62 |
6/6.19 |
9/9.33 |
12/12.47 |
19/18.76 |
0.0063/0.0069 |
11.24/12.42 |
2.5 |
325 |
1 |
60 |
7/6.93 |
9/9.28 |
14/14.00 |
19/18.71 |
28/28.13 |
0.0188/0.0208 |
33.84/37.44 |
0.6 |
|
2 |
56 |
6/6.47 |
9/8.66 |
13/13.05 |
17/17.46 |
36/26.26 |
0.0088/0.0097 |
15.84/17.46 |
1.0 |
400 |
1 |
119 |
14/13.47 |
18/18.41 |
28/27.76 |
37/37.10 |
55/55.8 |
0.0374/0.0412 |
67.32/74.16 |
1.6 |
|
2 |
110 |
13/12.70 |
17/17.02 |
26/25.66 |
34/34.20 |
50/51.58 |
0.0173/0.0190 |
31.14/34.20 |
2.5 |
500 |
1 |
185 |
|
|
45/4.15 |
55/57.68 |
85/86.74 |
0.0581/0.0641 |
104.58/115.38 |
|
|
2 |
180 |
|
|
40/41.99 |
55/57.68 |
85/86.74 |
0.0283/0.0312 |
50.94/56.16 |
|
600 |
1 |
269 |
|
|
60/62.7 |
85/83.88 |
125/126.13 |
0.0845/0.0932 |
152.10/167.76 |
|
|
2 |
266 |
|
|
60/32.05 |
80/82.94 |
125/14.72 |
0.0418/0.0461 |
75.24/83.98 |
|
700 |
1 |
379 |
|
|
90/88.41 |
120/118.17 |
175/177.71 |
0.0091/0.1313 |
214.38/236.34 |
|
|
2 |
358 |
|
|
85/83.51 |
110/111.62 |
165/167.85 |
0.0562/0.0620 |
101.16/111.60 |
|
800 |
1 |
511 |
|
|
120/119.20 |
160/159.16 |
240/239.60 |
0.1605/0.1770 |
288.90/318.60 |
|
|
2 |
488 |
|
|
115/113.83 |
150/152.16 |
230/228.81 |
0.0767/0.0845 |
138.06/152.10 |
|
900 |
1 |
649 |
|
|
150/151.39 |
200/202.36 |
305/304.3 |
0.2039/0.2248 |
367.02/404.46 |
|
|
2 |
630 |
|
|
145/146.96 |
195/196.44 |
295/295.40 |
0.0990/0.1091 |
178.20/196.38 |
|
1000 |
1 |
805 |
|
|
185/187.78 |
250/251.00 |
375/377.45 |
0.2529/0.2788 |
455.22/501.74 |
|
|
2 |
792 |
|
|
185/184.75 |
245/246.95 |
370/371.36 |
0.1244/0.1374 |
223.92/246.96 |
|
